AVPro Edge introduced an MXnet Evolution II encoder (model AC-MXNET-1G-DANTE-EV2), an MXnet Evolution II decoder (model AC-MXNET-1G-DANTE-DV2), and an MXnet Evolution II wall plate encoder (model AC-MXNET-1G-EV2WP). These new models add compatibility with Dante audio to the MXnet Evolution II series.

Installations that systematically deploy Dante audio but segregate it to an independent network can now simplify long-haul transport cabling to a single endpoint. Dante streams are ferried from the EV2 encoder to any EV2 decoder endpoint, bringing encoded signals closer to Dante devices. As an example, Dante-enabled amplifiers can be strategically located physically closer to the speaker systems they will power, potentially overcoming Dante’s 100-meter Category cable distance threshold while also minimizing the length required for analog speaker wire. Dante-equipped self-amplified speakers may also take advantage of merged centralized stream routes. Creative application of these new MXnet EV2 devices will result in significant material and labor savings for system deployments.

MXnet Evolution II Encoder features:

• Dante audio encoding
• High bitrate 3D Immersive Audio Compatible
• Optimized Video Compression for Artifact-free Images
• Support for HDR10, HDR10+ and Dolby Vision
• USB and KVM Support

MXnet Evolution II Decoder features:

• Dante audio Pass-through/Break-out Bridge
• High bitrate 3D Immersive Audio Compatible
• Optimized Video Compression for Artifact-free Images
• Support for HDR10, HDR10+ and Dolby Vision
• USB and KVM Support

The AC-MXNET-1G-EV2WP is an MXnet Evolution II encoder with selectable switching between HDMI and USB-C inputs packaged in an elegant, low-profile, PoE-powered wall plate. Similar in function to the model AC-MXnet-1G EV2, system encoding may now be placed anywhere as it’s a wallplate. A/V signals are converted into precision multicast data packets, routed to any or all system decoders via Category 6A cable tethered to an MXnet PoE network switch.

MXnet Evolution II Wall Plate Encoder features:

• Low Latency, Native 4K/60 fps Support
• Fits Standard NEMA Double-gang Wall Boxes
• HDMI/USB-C Dual-inputs with Analog Audio Follow
• Transformer-free, P-o-E Powered
• Inputs Locally Selectable
• Minimal Heat and Low Power Consumption
