Zigen Ships HDBaseT Extender

zigen-hdbaset-0315The Zigen ZIG-POE-70 is an HDBaseT transmitter/receiver set for HDMI transmission up to 230 feet (70 meters) over category cable with RS232 and IR control plus Power over Ethernet capability. The set transmits video signals up to 4K/UHD @ 60Hz with embedded multi-channel audio and remote 48V power for the receiver. The kit provides bi-directional extension of three to 12 V IR (IR Receiver included) and RS232 commands. Pigeon says the set is HDCP 2.2 compliant and supports EDID communication.

The ZIG-POE-70 sender provides a complete solution for detection and powering of POE IEEE 802.3af devices such as the ZIG-POE receiver/TV box. The sender will safely detect, classify, and provide up to 13 watts of power to the receiver via HDBaseT connection. The receiver reads a signature from the sender (TX) and only enables power delivery if all constraints for safe power delivery are met. During power delivery the link is continuously monitored for any fault or overloading conditions and the current is limited to avoid hazardous conditions.

The ZIG-POE-70 sender senses the removal of a powered device and turns the 48-volt power supply off immediately when the receiver is disconnected.

Here are all the specs.
