Rohde & Schwarz presents its top-notch RF and microwave test solutions at the EuMW 2024 in Paris
Premier microwave, RF, wireless and radar players gather in the city of light for the European Microwave Week (EuMW). Industry-leading T&M specialist Rohde & Schwarz will present a radiating portfolio of products and solutions in Paris for various application fields, pushing the limits in the Gigahertz to Terahertz frequency ranges.
Rohde & Schwarz will showcase its latest RF and microwave portfolio and solutions following the motto
“From Gigahertz to Terahertz” at this year’s European Microwave Week in Paris. At the exhibition, taking
place from September 24 to 26, 2024 in the Paris Expo Porte de Versailles venue, visitors can learn at booth
401L about the company’s top-notch applications to solve pressing test challenges RF engineers are facing
right now in component design and next generation wireless, as well as in the automotive and aerospace
and defense industries. Highlights will include EVM measurements and wideband modulated load pull analysis for RF frontends. A system for 6G wireless data transmission based on photonics will address state-of-the-art research for next generation wireless technologies. And disruptive innovations in automotive radar production and testing as well as industry leading-solutions for 5G NTN satellite testing will round out the
company’s display at the EuMW 2024.
Wide spectrum of RF and microwave component testing
Active components such as power amplifiers are integral for any RF frontend design. With increasing data
rates, complex modulation schemes are becoming critical in wireless connectivity applications. A low error
vector magnitude (EVM) at both the component and system levels is key to ensuring that these modulation
schemes are robust and stable. Given the unprecedented performance levels of these power amplifiers,
EVM measurements are a challenging task in RF frontend design. Rohde & Schwarz will present at the
EuMW its updated R&S SMW200A vector signal generator which comes with enhanced performance and
unparalleled flexibility to meet the most demanding EVM requirements ideal for power amplifier verification.
Equipped with the new linearize RF path software option, the signal generator enables better EVM/ACLR at
high output power with digital pre-distortion-based optimization. The high-end instrument perfectly matches
the industry-leading R&S FSW signal and spectrum analyzer. At the EuMW, however, the setup features the
powerful R&S FSVA3000 on the analysis side, including its unique IQ noise cancellation software-based
feature to achieve outstanding EVM measurement performance thanks to a noise corrected measurement
path.
Besides EVM, power amplifier efficiency is key in RF frontend design. The RF frontend drives signals into an
antenna for wireless transmissions in its intended application. These antennas are designed to have a
nominal impedance of 50 Ohms. However, due to their wide frequency coverage, the actual impedance can
often deviate significantly from 50 Ohms. The impedance encountered by the RF frontend greatly influences
its performance, while the influence on its performance and efficiency is unpredictable. Therefore, it’s crucial
to verify the performance across a range of impedance variations. To ensure the power amplifier’s target
specifications like minimized power consumption or optimized modulation performance, wideband modulated
load pull analysis is a vital method for characterizing nonlinear devices. At the EuMW, Rohde & Schwarz will demonstrate a new setup for wideband modulated load pull, featuring the R&S SMW200A vector signal
generator in combination with the R&S RTP164 oscilloscope. With this setup, RF engineers can verify the
system level performance of the RF frontend with different impedances and verify KPIs such as gain, EVM
and ACLR across varying impedance conditions.
For high-throughput RF component verification, Rohde & Schwarz demonstrates for the first time the
PVT360A performance vector tester equipped with a new high-power option. The single-box tester combines
two independent vector signal generators and vector signal analyzers in one instrument and provides
outstanding measurement speed, making it ideal for characterization and production environments. The new
option will provide up to 20 dBm RMS output power, making it well-equipped for any applications where high
input power to the DUT is required or where high losses can be expected. It now covers a frequency range
up to 8.5 GHz for additional potential frequency bands for the lower parts of 5G NR FR3 (7.125 GHz to 24.25
GHz). At the EuMW, visitors can get a first glimpse of the upgraded instrument version, which will be
available soon.
Also measuring jitter for clocks in high-speed digital designs is addressed at the Rohde & Schwarz booth.
With increasing data rates, the limits for overall system jitter become ever tighter, especially for the various
components of the clock tree. Phase noise analyzers are the instruments of choice for verifying the jitter
performance of clocks. With the R&S FSWP, Rohde & Schwarz will demonstrate at the EuMW the best
phase noise analyzer on the market, featuring highest sensitivity. It is ideal for super low phase noise and
jitter measurements even at frequencies above 50 GHz as needed for common electrical interface OIF
CEI-224G (56 GHz) or ultra-fast LAN IEEE 802.3dj (53 GHz). At EuMW, it is shown analyzing beyond 50
GHz with cross correlation, achieving most accurate results that reflect the true DUT performance.
Another demo will cover intermodulation (IM) measurements for 6G D band components. When
characterizing components for tomorrow’s 6G communications systems, developers have to test the
intermodulation of the active device in addition to the S-parameters. The R&S ZNA67 vector network
analyzer in combination with the R&S ZCDS170 dual source converters allows a simplified measurement
setup that directly provides a two-tone output signal for IM testing up to 170 GHz.
Next generation wireless technologies
The door to the 6G era has been opened and it will enable new application scenarios in industry, medical
technology and everyday life. This will bring about new requirements for latency and data transmission rates.
While sub-THz frequencies up to 300 GHz for communication within 6G networks will potentially be
introduced at a later stage, this frequency band will be indispensable to realize the full potential of the
metaverse and extended reality (XR) applications. On the path to 6G, it is important to create THz
transmission sources that offer high signal quality and cover as wide a frequency range as possible. In the
future, this might be achieved by integrating optical technologies with electronics. Such THz components
could be used beyond communications and data transmission, finding applications in sensing and imaging.
At the EuMW, Rohde & Schwarz will present its proof-of-concept for an ultra-stable tunable THz system for
6G wireless data transmission based on photonics. Developed within the 6G-ADLANTIK project funded by
the Federal Ministry of Education and Research of Germany (BMBF), it enables the photonic generation of
THz signals based on frequency comb technology. In this approach, a photodiode efficiently converts an
optical beat signal derived from lasers at slightly different optical frequencies into an electrical signal via a
photomixing process. The antenna structure surrounding the photomixer translates the oscillating
photocurrent into a THz wave. The resulting signals can be modulated and demodulated for 6G wireless
communications and can be tuned easily over a wide frequency range. The presented system also can be
extended for component characterization with coherently received THz signals. A THz waveguide
architecture simulation and design as well as the development of ultra-low phase noise photonic reference
oscillators are also part of the scope-of-work for this project.
Another highlight at the Rohde & Schwarz booth will be a setup for wideband signal generation and analysis
in the H band, featuring the new R&S SFI100A wideband IF vector signal generator combined with the new
R&S FC330ST/SR frequency converters. The signal generator generates signals with up to 10 GHz RF
modulation bandwidth, the frequency converters are designed to up- and down-convert the intermediate frequency (IF) signals to and from the RF frequency range of 220 to 330 GHz, known as H band. Their high-performance balanced mixer with low conversion loss ensures precise measurements. An additional integrated IF amplifier helps to achieve exceptional sensitivity and signal performance. The solution supports an IF range of up to 35 GHz, allowing for ultra-wide bandwidth signals to be transmitted and received. The R&S RTP oscilloscope is used in the demo setup to receive the down-converted IF signals. Equipped with the versatile R&S VSE signal analysis software the baseband signals can be analyzed directly on the instrument. The H band is gaining importance for various applications not just for 6G research but also in radar technology or advanced imaging for security and healthcare.
Next level automotive radar production testing
Next-generation radar, pivotal for the evolution of ADAS and autonomous driving, requires test solutions that
deliver unrivalled accuracy, efficiency and reliability. To drive this development further, Rohde & Schwarz will
bring two radical innovations in automotive radar production testing to the EuMW, offering the industry a
hitherto unseen price-performance point. The R&S RadEsT (Radar Essential Tester) automotive radar target
simulator emerges as an ultra-compact, versatile tool designed to meet a wide array of vehicle manufacturer
testing needs, from lab-based functional testing to vehicle-level production checks. With its impressive array
of features and exceptional value, it opens up new possibilities for precise, reliable, and dynamic radar
testing. The Radar Essential Tester addresses a wide spectrum of use cases, from system checks and
debugging of radar module reference designs to software verification and functional tests on the radar
module. It is an ideal fit for OEM end-of-line testing, that provides advanced testing capabilities for radar
alignment and calibration as well as functional check during production beyond the limited functionality of
passive reflective elements that have historically been used. Furthermore, the R&S RadEsT has the
capability to test advanced driver-assistance systems (ADAS) and autonomous driving (AD) functions.
In addition, Rohde & Schwarz also introduces new “mini”, “golden”, “pro” and “golden-pro” versions of its
automotive world’s leading radar echo generator R&S AREG800A. The resulting new R&S AREG-P target generator helps Tier1 automotive radar manufacturers to increase throughput, reduce costs and reduce end-
of-line test time. EuMW visitors can learn how the solution creates the perfect environment for the radar sensor’s seamless transition from R&D to production, optimizing OPEX, CAPEX and time to market.
Cutting-edge solutions for aerospace and defense
To ensure that communications systems based on 5G non-terrestrial networks (NTN) and LEO constellations
work reliably and efficiently, testing is crucial. To this end, Rohde & Schwarz will present dynamic fading test
scenarios for LEO satellites and terminals that mimic realistic LEO and MEO satellite trajectories at the
EuMW. With a new software update, the R&S SMW200A vector signal generator now allows for Doppler
shifts of up to 1.9 MHz, enhancing the simulation of high-speed satellite movement. A new user-friendly
software makes creating and uploading fading profiles easy. In combination with the instrument’s frequency
range up to 67 GHz, it opens up new possibilities to develop extremely-high-frequency satellite
communications. The same setup also demonstrates testing of Ka-band power amplifiers in development
and verification. For this application, generating multi-carrier CW signals up to 2 GHz bandwidth is vital in order to obtain repeatable test results. Additionally, generating realistic test signals such as DVB-
S2/S2X/RCS2 and custom OFDM allow the analysis of the power amplifier under real-world satellite scenarios. The R&S FSW signal and spectrum analyzer equipped with an amplifier measurement application
is ideal for analyzing the characteristics of these devices, providing insights into various parameters such as
Error Vector Magnitude (EVM), AM/AM and AM/PM distortion, group delay, and Adjacent Channel Leakage
Ratio (ACLR), which are critical for assessing the performance and reliability of communication equipment.
mmWave imaging technology with ISAR processing
Rohde & Schwarz continues to evolve its millimeter wave imaging technology for different use cases. At the
EuMW, the company will exhibit its imaging capabilities that leverages hundreds of receive and transmit
antennas to quickly characterize materials in a new context. The solution is ideal for detecting quality issues
of packaged goods such as leakage, missing or incorrect items as well as unwanted particles within the
package through real-time analysis. This in-line quality inspection method works with non-ionizing radiation
and provides users with another form of non-destructive testing, complementing current methods such as
cameras, X-rays or scales in logistics, food or pharmaceutical environments. The new R&S IMAGER
presented in Paris uses live inverse synthetic aperture radar (ISAR) processing, which reveals details and
defects that cannot easily be detected with alternative testing methods.
Service and calibration in great hands
Leading-edge technology belongs in expert hands. The Rohde & Schwarz support network spans multiple
time zones and reaches all corners of the world. At the EuMW, Rohde & Schwarz will also spotlight its
comprehensive service portfolio. Visitors can learn about accredited calibration services, repair services
directly from Rohde & Schwarz, training courses and industry insights from the R&S Technology Academy,
and the 24/7 hotline service as well as on-site support.
Rohde & Schwarz will be exhibiting at booth 401L in Paris Expo Porte de Versailles from September 24 to
26, 2024. In addition, experts from the company will contribute with presentations and workshops to the
program of the European Microwave Conference (EuMC), the European Microwave Integrated Circuits
Conference (EuMIC), as well as the Defense, Security and Space Forum. Information on the company’s
demonstrations, including the possibility to register for free exhibition tickets, is also available at:
https://www.rohde-schwarz.com/eumw
