Hall Research Announces HDMI Audio Inserter & Extractor

Tustin, California, USA – April 22, 2019 Hall Research, a California based manufacturer of AV signal management equipment is pleased to announce the HD-AUD-IO, an all-in-one HDMI audio manager capable of extracting audio from (de-embedding) and/or inserting audio into (embedding) an HDMI video signal. Features include advanced EDID management and ability to create Audio-only HDMI output.

The HD-AUD-IO provides one HDMI input with a corresponding output. The audio embedded in the HDMI input is extracted and available as both stereo analog or multi-channel digital SPDIF (TOSLINK).  The product provides two audio inputs (analog and digital). Users can select which audio to embed in the HDMI output. It can be the same as the original HDMI audio (pass-thru), SPDIF digital, or 3.5mm L/R analog.

An excellent solution for environments where the audio needs to follow a different path than the video in places such as sports bars, houses of worship, retail stores, and other similar situations. Since the product can extract and embed audio at the same time, with the use of an external mixer, user’s are able to mix auxiliary audio (e.g. from microphone) with the original HDMI program audio.

The audio in the HDMI output can be muted using discrete (contact closure) input or RS-232 commands. The HD-AUD-IO is capable of generating an HDMI output even with no HDMI input. This can be used to distribute HDMI with only audio (black screen) to TVs.

Advanced EDID management allows users to control the video portion as well as the audio part of the EDID. The EDID presented to the video source can pass from the downstream device or emulated from internal memory. The device can also “Learn” the EDID connected to its HDMI output.

The product has a video bandwidth of 18 Gbps and supports resolutions up to 4K @ 60 Hz 4:4:4 with HDR. It supports HDCP 2.2 as well as HDCP 1.4.
