A new update for the Atomos Shogun 7 HDR monitor-recorder-switcher (AtomOS 10.4) was released today, and it adds touch-controlled switching, quad monitoring and ISO recording functionality. This allows the user to switch back and forth between four live HD SDI video streams (up to 1080p@60Hz). Tapping on an input stream’s window (while in the quad-view mode) will switch to that source as the program feed; that feed is then output via HDMI, SDI or both simultaneously. You can record all four streams, with the switched program output as a fifth stream. This is all done asynchronously, without the need for genlocked sources.
The streams are all recorded to the same high-performance SSD drive and can be ready to edit moments after the shoot has finished. Each is recorded as a separate ISO in either Apple ProRes or Avid DNx, providing post-production with creative advantages and the convenience of having multiple, synchronized camera angles when they come to craft the story in the edit suite.
All input switches are recorded in metadata with a choice of transition type. Once you’ve finished capturing your streams, import the resulting Apple Final Cut XML file along with your ISOs into your NLE and the timeline automatically populates with all the transitions in place.
Plus, every ISO can record the two-channel embedded digital audio from each source, as well as analog stereo channels coming into the Shogun 7 (via optional XLR breakout cable). The program stream always records the analog feed and can switch between audio inputs for the on-camera audio to match the switched feed. On-screen, you can choose to view the four input streams at once in a quad-view, or a full-screen view of any one of the four input streams. In full screen, you can access tools like waveforms, magnify or engage peaking check focus for each angle and make any adjustments to get the perfect HDR or SDR shots.
