1 Sound Adds New Contour CT212 3-Way Passive Loudspeaker
The new Contour CT212 from 1 Sound is a horn-loaded three-way passive loudspeaker capable of delivering a maximum SPL of 145 dB. The Contour combines two 12″ low-frequency drivers and a coaxial 4″ + 2″ mid-high compression driver in a horn-loaded point source enclosure. The CT212 delivers a controlled 100° x 50° dispersion maintaining “constant directivity down to 200 Hz, with a bass response down to 55 Hz.” With various rigging options, this loudspeaker claims to be ideal for medium to large-scale installations and live production audio. The CT212 is IP55 rated and saltwater resistant, with stainless steel 316 accessories available.
Features and Specs:
- Passive, three-way loudspeaker, horn-loaded point source
- Bandwidth: 55 Hz – 20 kHz (-6 dB preset dependent)
- Max SPL: 145 dB @ 1m with preset
- Power: 3600 watts LF + 380 watts MHF (program), 1800 watts LF + 190 watts MHF (AES)
- Directivity: 100° x 50°
- Elements: (2) 12” low-frequency drivers, (1) 4” mid-high coaxial with a 2” compression driver
- Impedance: 4Ω LF + 16 Ω MHF
- Connectors: (2) NL4
- IP Rating: IP55 indoor/outdoor and salt water resistant
- Rigging: (8) M5 points, (4) M6 points
- Weight: 91.8 lbs / 41.6
- Construction: Finland birch plywood (urea glue), matte salt and UV resistant polyurea coating, 316 stainless steel and aluminum hardware, 3D spacer mesh fabric
- Accessories: CT212 Horizontal Mounting Bracket, CT212 Wall Bracket, CT212 Rigging System, Tube Mount, removable magnetic front grille included
- Dimensions: 20.6” (525 mm) x 18.1” (460 mm) x 30.8” (783mm)
