Pasternack Debuts 75 Ohm Cables Up to 3 GHz

pasternack-cable-0315Pasternack announced the release of its newest line of 75 ohm test cables with operation up to 3 GHz. Pasternack claims that these cables are rugged cable assemblies that are specially designed to withstand the rigors of test lab use and applications in 75 ohm communications systems. Technicians commonly rely on these high frequency test cables in technologies such as cable TV, MoCA 2.0 and MoCA 1.1 (Media over Coax Alliance) and DOCSIS (Data over Cable Service Interface Specifications).

Pasternack’s new series of high performance 75 Ohm test cables are available in two configurations including a type-N male to type-N male or a type-N male to type-F male. Unlike most F connectors readily available on the market, these F connectors are designed to perform up to 3 GHz which greatly broadens the usability and value of these test cables. Moreover, these connectors are threaded to ensure an accurate and secure connection to both the device under test as well as the analyzer. The test cables are suitable for engineering labs, production environments and quality testing facilities and are a good choice for use with 75 ohm S-parameter test systems.

The new 75 Ohm flexible armored test cables from Pasternack exhibit excellent insertion loss of < 0.5 dB @ 3 GHz, and typical return loss is 28 dB. These new RF cable assemblies are designed with an armored jacket that meets ANSI/SCTE 99 2009 pull force and ANSI/SCTE 98 2009 tightening torque standards and are also capable of 100,000 bends minimum.

Here are all the specific details.
