Extron Ships Fiber Optic Extenders for 4K

fox2thd4k-lg-0516Extron is shipping its new FOX II 4K Series for extension, switching and distribution of 4K video (up to 30 Hz with a 4:4:4 color space over one-fiber or @60 Hz with a 4:4:4 color space using two transmitters), multi‑channel audio, and bi-directional control signals over fiber optic cabling. The series includes the FOX II T DP 4K and FOX II T HD 4K fiber optic transmitters for DisplayPort and HDMI, as well as the FOX II R DP 4K with a Type 2 dual‑mode DisplayPort output to support DisplayPort and HDMI 4K resolution displays. They use Extron all‑digital technology for reliable delivery of video signals at resolutions up to 4096×2160. These extenders are HDCP-compliant, and expand the capabilities of the Extron FOX Series fiber optic products. Available in multi-mode and single-mode models, the FOX II 4K Series extenders are ideal for point-to-point installations or in combination with a FOX Matrix Switcher for an enterprise-wide 4K video distribution system.

The FOX II 4K Series fiber optic extenders provide signal extension for moderate distances of up to 2 kilometers (1.25 miles) over multi-mode fiber optic cable and extreme distances up to 30 kilometers (18.75 miles) when using single-mode cable. Both transmitters include a buffered loop-through for a local monitor at the source. Also, the FOX II R DP 4K provides audio de‑embedding and balanced return analog stereo audio output to support a remote audio source at the receiver. Other integrator-friendly features include Key Minder, EDID Minder, audio embedding, audio gain and attenuation adjustment, bidirectional RS232 and IR control, and real‑time system monitoring. Also, optional mounting kits such as the MBU 125 under-desk mounting kit allow signal extension from a source in a lectern to a remote display or central control room. These extenders are simple to set up and commission using Extron’s PCS – Product Configuration Software.

See related  THE rAVe Esports Show — Episode 9: Inside the Venue: Unveiling the Tech Powering West Point Academy's Esports Arena

The specs on the FOX II DP 4K are here and the FOX II T HD 4K specs are here.
