Volume 8, Issue 7 — July 9, 2015
|
|
The Video “Easy Button”
By Scott Tiner rAVe Columnist
Several years ago, Staples developed the marketing campaign of the Easy Button. The concept was that going to Staples was as easy as pressing a single button and getting what you needed. I always thought that this should be the concept for touchpanels and control systems in our classrooms. Yet, there always seems to be more needed than that one button can manage.
Last year we opened a new Digital Media Studio. The space includes high end editing suites, a computer lab and an amazing multimedia studio, with lights, cameras, sound and various colored backdrops. The studio is fabulous because we can create very high end, professional video in the space. Our students have the opportunity to learn about lighting, sound and other skills needed for quality video.
As video needs continue to grow at our institution and all other educational institutions, we have more and more customers who want “quality” video, but don’t want to learn how to use all the equipment in the studio. They want a final product, not a technical education, much like our faculty simply want to present in a classroom, not spend time learning how to hook up equipment. Many of our faculty had done some recordings in their office with their laptops’ webcams and microphones, but were not satisfied with the results. We were stuck between customers wanting a product that was easy to create, but looked and sounded better than what they could do in their office.
Our digital media specialists came across an interesting installation at Penn State, the One Button Studio. The design of the studio is well documented on Penn’s website, but what is so interesting is the ease of use for users. Users literally walk into the studio and insert a thumb drive into a USB hub. That automatically turns the system on. Lights, Camera, Action! When the customer is ready to start recording, she presses a button, kinda like the easy button. When finished, she presses it again. She grabs the thumb drive and is on her way with a professional looking and sounding recording.
This summer we are planning a similar installation. Due to our specific needs, it is not likely we will use the One Button software, but our installation is intended to be just as easy to use. Our customers have already come to us with several projects that the room will serve well. One of the uses is for our student academic support group to have students give run-throughs of presentations in the room and record them. Then, they sit down together and review the presentation and help with any changes that need to be made. A second, and obvious use, is for faculty to add video recordings to their class offerings. Whether this is intended as part of a flipped classroom, or simply additional tutorials is dependent on the needs of the faculty.
We also have several other administrative users who desire to record technical training or provide training on issues like Title IX compliance. Rather than perform these activities over and over again, they will be able to stop by the studio and easily make a recording, and then post it on their website.
For an integrator, this type of room provides an excellent opportunity to offer value to a school. If you are able to understand how this room works, and able to listen to your customers about what their specific needs are, you can offer them a solution that is unique, and profitable. Perhaps the biggest challenge for an integrator will be to make it simple. A challenge because your customers will continue to tell you about additional needs and desires. Yet, you will need to keep in mind that the primary desire is simplicity. The goal of our studio will be to NOT have to do any training at all. It will be so simple that people can walk in the first time and start using it. As you deal with customers you may need to remind them of that primary goal. It is likely you will also need to remind your designers about it, as they may tend to want to add features and equipment. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
|
Datapath Launches the VisionSC-DP2 Dual Channel DisplayPort, 4K/60 Capture CardDatapath launched of the VisionSC-DP2 — the first video capture card in the new VisionSC range and the worlds first DisplayPort 1.2 capture card supporting full 4K at 60 fps.
The VisionSC-DP2 offers users the ability to simultaneously capture two channels of DisplayPort 1.2. Each channel can capture video and audio up to 4096x2160p at 60 FPS for crystal clear video. The VisionSC-DP2 also supports Datapath’s LiveStream technology for lowest possible capture latency. The card is supported by the high performance Vision Driver common to all Datapath capture cards, offering a vast number of features and providing ease of use for system integrators and software developers alike.
Datapath VisionSC-DP2 key features and benefits:
- Two independent channels of DisplayPort 1.2 video and audio capture
- LiveStream low latency technology supports high performance real time capture
- Multi-stream allowing for the independent control of multiple streams from a single capture channel at the same time
- Automatic signal detection enables simple connection and capture of sources
Hardware based common time stamping facility
Datapath’s capture cards are used around the world in a wide variety of applications from Video Wall Controllers, Flight Simulators, Lecture Capture Applications, to Medical applications and much more.
For further information, go here. Leave a Comment
Share Article
Back to Top |
Kramer Unveils New 12-Input ProScale Digital Scaler/Switcher at InfoCommKramer introduced its newest ProScale Presentation Digital Scaler/Switcher at InfoComm 2015. Dubbed the Kramer VP-444, it features 12 inputs (with fade-thru-black switching), 10 HDMI inputs and two analog inputs. The VP-444 offers unbalanced stereo inputs for each video input and embedded audio for its HDMI inputs. Level control is available for the outputs as well as for each individual input. It scales the video, embeds the audio, and outputs the signal to two HDMI outputs (up to 1080p). The product includes 22 output resolutions.
Integrated with two microphone inputs for mixing, switching or talkover, the VP-444 also has two audio outputs with balanced stereo audio on a terminal block connector and S/PDIF on an RCA connector. The unit features last-connected auto input switching, offering users plug-and-display functionality.
The VP-444 features control via RS-232 and IR remote with on-screen display (OSD) and easy-to-use, built-in web pages via Ethernet. The unit also features powerful audio DSP functions for digital audio signal processing, including audio equalization, mixing, delay, etc.
The VP-444 is housed in a standard 19” 1U rack-mountable enclosure with rack ears and all the details are here. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
InFocus LightCast Technology in Collaboration Solutions Enables Wireless Device Display and eWhiteboarding InFocus Corporation today introduced its LightCast technology, which they say enables BYOD connectivity and all-in-one digital whiteboarding and Internet browsing. The company is also launching its first device with the new technology built in, the interactive touchscreen JTouch with LightCast (INF6501c).
InFocus’ LightCast technology allows people to wirelessly cast content from their Windows, Apple OSX and iOS, and Android devices to a display screen or projector. LightCast devices also offer whiteboard tools, which let users draw, highlight, annotate and capture notes that they can share with anyone via email. Rounding out LightCast’s functionality is a Web browser to enable Internet access without being connected to a separate device.
To showcase the new technology, InFocus is simultaneously announcing a new interactive display, the 65-inch JTouch with LightCast (INF6501c). InFocus based this five-point touch display on the popular InFocus JTouch display platform, which connects with Windows, Macs and Chromebooks and provides a bright, colorful touch experience that engages audiences and combines interactivity with affordability. With LightCast embedded, JTouch becomes an even more powerful, interactive tool enabling a myriad of options for enhanced collaboration and learning. With LightCast-enabled devices, users can save and share lessons as well as use them again for subsequent classes. This advanced note taking is tangible in business applications as well, with LightCast allowing immediate access to web resources which improves meeting efficiency.
InFocus JTouch with LightCast supports edge-to-edge IR touch and Windows 7/8 gestures. It offers integrated stereo speakers for 20W stereo sound along with incredible connectivity including four front-facing USB ports for instant access as well as four HDMI ports, DVI, VGA (HD15 VESA), four USB Type-A, 3.5mm stereo audio in, 3.5mm stereo audio out, USB Type-B port for touch screen control.
InFocus LightCast technology is also built into the just-released Mondopad 2.0 collaboration system. Using Mondopad’s new casting feature one can now connect and display from almost any device for additional idea sharing. While casting to Mondopad, users can also annotate on the display, taking interaction to the next level.
InFocus will include LightCast technology in more products launching later this year, including InFocus projectors and interactive displays.
The JTouch with LightCast is available directly from InFocus here and from InFocus resellers for $3,299 list ($2,399 for K-12 schools). Leave a Comment
Share Article
Back to Top |
BenQ Expands Digital Signage Display SeriesBenQ America has announced the availability of four new models in its digital signage series, which will debut at InfoComm 2015. The so-called next-generation signage solutions include the company’s all-new 4K displays, interactive touch panels, ultra-slim monitors for video wall applications, and more.
The four include two new additions to the RP Series of interactive flat panels that feature 10 touch points, the 79-inch 4K RP790 and 70-inch RP702. Equipped with DisplayNote, a free bundle desktop and mobile application, presenters can create more collaborative environments by streaming any content directly from their computers to multiple participants across various devices. Aimed at classroom and other collaborative environments, BenQ’s QWrite software enables onscreen user interaction by editing, highlighting, and co-creating a wide range of documents.
One of the other new models is the 55-inch PL550 (with a bezel-to-bezel gap of only 3.5mm) and integrates HDMI digital daisy-chain capabilities, direct USB flash drive connectivity, video-over-Ethernet (VoE), and BenQ’s MDA software tools. Finally, the fourth is a new 4K2K resolution display spec’d at 350 nits of brightness. The 55-inch ST550K is an ultra-slim signage solution equipped with the X-Sign content creation and management software, MDA software, and a custom Android operating system that enables USB playback and Mobile High-Definition Link (MHL) connectivity to allow mobile devices to mirror HD content to the monitors, the ST550K is an all-in-one smart signage solution packed with everything needed to deploy and manage content in retail shops, restaurants, and corporate settings.
All three can be found here. Leave a Comment
Share Article
Back to Top |
Kramer to Launch Classroom SystemAt InfoComm, Kramer will unveil a wireless classroom solution that combines Kramer’s VIA Wireless Presentation and Collaboration solutions, Kramer K-Touch 3.0 Cloud-based control platform and Kramer HDMI/HDBaseT signal distribution in a packaged configuration.
Called the Kramer Collaborative Classroom the hub is their VIA Connect PRO for small group collaboration at tables or huddle spaces. Kramer’s K-Touch 3.0 control system, integrated with Kramer’s VIA Collage, allows the teacher to control and manage local group displays. The teacher can share local displays instantly with any other group or the entire class or even turn them on and off. Anyone can easily use K-Touch 3.0 with any iOS or Android tablet.
For a classroom with 25 students, the Kramer Collaborative Classroom would include up to five VIA Connect PROs, one VIA Collage, K-Touch 3.0 control, a Kramer VS-88DT HDMI/HDBaseT switcher, and Kramer HDMI/HDBaseT range extenders.
When it’s on their website, it will be here. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
Just Add Power Adds Image Play Video Tiling to HD Over IP More Play Feature SetAt InfoComm 2015 Just Add Power debuted the 2G+4+ Tiling Transmitter with Image Play, which gives integrators the ability to display multiple video feeds on a single screen. The 2G+4+ device is a 1U rack-mountable video tiling processor that enables commercial integrators to deliver four HDMI sources to a single screen in a variety of viewing modes over a Gigabit managed network.
The 2G+4+ four-input video tiling processor works with the entire family of 2G/2G+/2G+AVPro devices. It can be mixed and matched in the same network as earlier 2G/2G+/2G+AVPro transmitters and receivers. The backwards compatibility of the 2G+4+ tiling processor allows it to be added retroactively to existing 2G and 2G+ installs with maximum ease for the installer and minimum down time for the site.
One 2G+4+ Tiling Transmitter allows you to watch up to four HDMI sources at the same time on a single display in a variety of viewing modes, including quad view, picture in a picture, and picture on a picture. You can also stack up to five 2G+4+ units and, as a result, actually view up to 16 images simultaneously on a single display. Additionally, an HDMI pass-through port on the 2G+4+ Tiling Transmitter allows for distribution to a local mirrored display.
Here are the details. Leave a Comment
Share Article
Back to Top |
Aurora Ships QXT-700 Control PanelAurora is now shipping the QXT-700 7-inch HD control panel — a 1280×800 touch screen for their control system. Powered by a quad-core processor with a PoE-enabled 1-Gbps LAN port, multiple on-board RS-232/IR/relay ports, and DIO, the QXT-700 is designed for any conference room, classroom or hospitality A/V control application.
Designed for integration with smartphones and tablets, the platform-agnostic QXT-700 features a built-in Web server for Apple, Android, and Microsoft devices — with no apps or license fees required. A new Android version is in development that will allow users to incorporate Android-based apps from other A/V manufacturers and run them seamlessly within the QXT-700, allowing users to have the best of both worlds with streamlined programming.
The all-in-one control panel features stereo speakers, stereo digital microphones, a light sensor, proximity, and IR learner. The unit mounts onto any surface with a standard two-gang low-voltage box. The QXT-700 lists for $1799 and all the specs are here. Leave a Comment
Share Article
Back to Top |
BTX Announces New BookIT Room Scheduling SolutionBTX Technologies announced today that they are entering the room scheduling market with BookIT. BookIT will debut at InfoComm 2015 and will be available for sale in Q3 2015.
With BookIT, a meeting can be quickly scheduled using the touch panel display at the conference room site, a computer from an office or a mobile device. It’s integrated with the most popular scheduling programs including MS Exchange, Office 365 and Google Apps for Work, ensuring availability of the room and the people needed to host a successful meeting.
The BookIT system includes a sleek 7″ PoE touch panel device, simple wall mounting system with brackets and scheduling software. It features simple meeting check-in, extension and release of room, alternative room options, one cable installation per display and an intuitive interface which requires little to no training.
Details will be posted here. Leave a Comment
Share Article
Back to Top |
Extron Intros New 4K Presentation Matrix Switcher with Seamless SwitchingExtron has launched a new DTP CrossPoint 108 4K presentation matrix switcher. The DTP CrossPoint 108 4K includes a 10×8 matrix switcher with 4K inputs and outputs, four built-in 4K scalers (powered by Extron Vector 4K scaling technology) seamless switching and logo insertion, integrated DTP and XTP signal extension, audio DSP and AEC capabilities, a mono or stereo amplifier and an advanced control processor that is expandable.
The DTP CrossPoint 108 4K can immediately be integrated with the latest 4K sources and displays. Four built-in Vector 4K scalers are paired to the DTP outputs and enable independent scaling up to 4K. Extron says their new Vector 4K scaling engine is specifically designed with best-in-class image upscaling and downscaling, with 30-bit processing (most are 10-bit at best). The DTP twisted pair inputs and outputs provide flexibility in distributing AV and control. They can be used to connect to any display with an HDBaseT input, or tie into a centralized, facility-wide XTP System to add local room-based AV systems. Customize scaled outputs using the professional source transitions that are available, or insert a custom logo into the background or foreground.
The integrated audio DSP technology features all of the audio processing tools and capabilities of a fully equipped, professional outboard DSP (like the Extron DMP 128). The DTP CrossPoint 108 4K also includes four independent channels of high performance AEC for conferencing applications. A unique digital audio expansion port links the internal DSP to a DMP 128 for expanded I/O capacity to support additional microphones or speaker destinations. Additionally, the built-in mono or stereo 100 watt amplifier features the same Extron core technologies found in the renowned ENERGY STAR qualified XTRA Series, delivering high energy efficiency and professional grade audio performance.
DTP CrossPoint 108 4K IPCP models feature an integrated Extron IP Link Pro control processor, with the advanced features, processing power, and breakthrough technologies found in the standalone Extron IPCP Pro 350 control processor. This allows for complete, customizable control of an entire AV system. The purchase of an Extron LinkLicense with the DTP CrossPoint 108 4K IPCP allows a tablet or laptop to serve as the primary control interface for the AV system.
All the specifics are here. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
AtlasIED Launches Strategy III Series In-Ceiling SpeakersAtlasIED just launched the FAP Strategy III Series ceiling loudspeakers integrated with a Safety First Mounting System (SFMS). This technology prevents mounting tab damage during installation that other offerings suffer. The damage is caused by over torqueing during the installation process. This excessive torque can damage the mounting tabs that over time can increase the chance of mounting tab breakage and the loudspeaker falling from the ceiling. The SFMS is the result of over 100 tested prototypes until the final design was approved. This patent pending technology uses t-handles that are integrated into the front of the loudspeaker baffle to tighten the mounting tabs in materials up to 3/4″.
According to AtlasIED, the SFMS also decreases installation time by up to 60 percent. Its mounting design is simple install steps without the need for any tools. A front mounted 70V tap selector allows installers to quickly adjust and set the 70V power taps. A removable four-pole euro-style connector allows for easy pre-wiring and daisy chaining of additional loudspeakers and subwoofers. The result is fewer labor costs and better profits. The improved waveguide design provides wider coverage than previous models. The benefit is cost savings due to fewer loudspeakers required, while still maintaining uniform sound throughout. Low-frequency response is enhanced and deeper bass definition is provided via the optimized low frequency tuning port. Additionally all models are safety listed to both UL1480 and UL2043.
All the details are here. Leave a Comment
Share Article
Back to Top |
FSR’s HuddleVU Offers Adds Features, Offers New Mini-VU ModelFSR’s HuddleVU Collaboration system is designed as a meeting room system where users can share and view their multiple inputs; laptops, tablets, and smart phones, on a single or multiple displays. When FSR’s new DV-MFMV-74 DV PRO — MultiVU — Seven Input Multi-Format Windowing Scaler is integrated with the HuddleVU FLEX System. it creates a seven-input/user system that has a windowing 4Kx2K output with seamless switching and easy integration with all HuddleVU Collaboration Furniture.
The HuddleVU’s switcher line is rounded out with the availability of collaboration solutions where only two inputs are needed. FSR’s new DV-HSW-21A 2×1 HDMI switcher and the DV-MFSW-21A is a HDMI + VGA & Audio to HDMI switcher integrate with one FSR T3 table box for small collaboration or huddle kiosk-type solutions. To compliment these new smaller offerings, FSR is proud to now offer the Mini-VU Small Group Collaboration Table for two to four users/inputs while the larger tables are built to accommodate 4, 5, 6 or 7 users/inputs. All tables are available in counter or table height and can be used with or without the vertical back panel for mounting displays. The Mini-VU is crafted furniture designed for collaboration, functionality, and form. If time is a concern, stock models are available, or a furniture finish from the Wilsonart Line of Quality laminates can be chosen for a custom table.
Here are the details. Leave a Comment
Share Article
Back to Top |
Dynamic Microphones Go Mobile With MXL’s New MM-131 Mic Mate MobileMXL Microphones introduces the MXL MM-131 Mic Mate Mobile, a portable dynamic XLR-to-USB interface that works with computers and mobile devices. The Mic Mate Mobile is compatible with iOS products via the Apple camera kit. The Mic Mate Mobile turns a single dynamic microphone into a USB mic and a Mobile Media microphone, creating three distinct applications.
No special drivers are required to use the Mic Mate Mobile with a PC, Mac, iPhone or iPad. The Mic Mate Mobile is USB 1.1 and 2.0 Compatible and it adapts to any dynamic microphone.
The Mic Mate Mobile has an XLR connection on one end with a USB out on the other. A gain control knob lets the user adjust the sensitivity. The 1/8” headphone jack has its own volume control. The user can monitor audio with zero latency whether he is recording into an iPhone, iPad or a PC.
The $79.95 MXL MM-131 Mic Mate Mobile is here. Leave a Comment
Share Article
Back to Top |
Powersoft Unveils Its Ottocanali Series Amplifiers at InfoCommAudio manufacturer Powersoft announced the expansion of the successful Ottocanali Series, with the addition of three new high-performance eight-channel power amplifiers — under the series Ottocanali DSP+D. The Ottocanali Series DSP+D offers a wide range of system control and monitoring functions as well as sound shaping options, a total of up to 12,000 W output power at 4 ohms over 8 channels for lo-Z or distributed line systems — all packed into a double rack unit.
As with former versions of Ottocanali, the new DSP+D versions feature switchable main and aux signal inputs per channel, adequate GPIO, alarms, Lo-Z and Hi-Z output connections as well as mono-bridgeable channel pairs. These 2 RU models implement two redundant universal switch mode power supplies with PFC (Power Factor Correction) and patented SRM (Smart Rails Management) technology that maximize the efficiency of the system, while drastically reducing power consumption.
With two redundant Dante by Audinate digital streams, the Ottocanali 4K4 DSP+D, Ottocanali 8K4 DSP+D and Ottocanali 12K4 DSP+D will fit any venue as a stand-alone unit, making it ideal for multi-zone applications in mid to large-scale installs.
The DSP features of the Ottocanali DSP+D make these amplifiers ideal to seamlessly integrate into any installed sound or touring environment. In just two rack unit spaces, the design features a fully configurable input / output non-boolean matrix, with state of the art DSP. Also, since the Ottocanali DSP+D features dual redundant power supplies — claiming it as an industry first.
The new Ottocanali DSP+D system is fully compatible with Powersoft’s innovative Armonia Pro Audio Suite, making it easy to facilitate online or offline system set up and tuning. The Armonia platform also enables users to quickly and conveniently manipulate advanced DSP features of the system, such matrix / speaker routing and redundancy priorities, while managing and monitoring all vital functions in real-time from a remote PC via a single intuitive GUI.
All the details on the Powersoft Ottocanali DSP+D series are here. Leave a Comment
Share Article
Back to Top |
Hitachi’s CP-BW301WN and CP-BX301WN Short Throw LCD Projectors Are Aimed at ClassroomsHitachi America is introducing its CP-BW301WN and CP-BX301WN Short Throw LCD projectors designed for classroom installation that demands a projector refresh utilizing the existing wall-arm mount.
The new CP-BW301WN provides WXGA 1280×800 resolution with 3,000 lumens brightness and CP-BX301WN provides XGA 1024×768 resolution with 3,200 lumens brightness for more vivid and realistic images up to 150 inches diagonal. Both Short Throw projectors offer a Throw Ratio of 0.4:1 and deliver a 10,000:1 contrast ratio and lamp life up to 10,000 hours.
The projectors compact size and light weight (13.6″ x 11.9″ x 3.4″, 8.4 lbs.) make them easy to install on a wall-arm mount or place on a tabletop or other surface. They include two HDMI inputs, two computer and composite video inputs, a video monitor out and multiple audio connections. In addition, the CP-BW301WN and CP-BX301WN provide USB Type A and USB Type B ports, an RS232 connection for remote system control and an RJ-45 port that enables the projector to be remotely controlled and monitored via LAN. The CP-BW301WN and CP-BX301WN can also receive and display notifications and other information from a centralized location via a school’s LAN using Hitachi’s PJMessenger function.
All the detailed specs are here. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
Atlona Intros Eight-Input 4K Classroom SwitcherAtlona today launched the AT-UHD-CLSO-824, an eight-input, two output, 4K/UHD @ 60 Hz matrix switcher with mirrored HDMI and HDBaseT outputs. The latest addition in the company’s CLSO series of multi-format matrix switchers designed for commercial and education use, the CLSO-824 incorporates three HDBaseT and four HDMI inputs, one VGA analog video input and two HDBaseT outputs, each with a mirrored HDMI output.
Features such as two microphone inputs with 48 V phantom power, Ethernet-enabled 328 ft. (100 m.) HDBaseT signal extension, 10 local RS-232 ports, balanced analog stereo output, and a web-based GUI for switcher configuration are designed for integration.
With mirrored HDMI and HDBaseT outputs, the matrix switcher can also be used as a confidence monitor, dual displays, and divisible rooms, with one screen per room. The AT-UHD-CLSO-824 accepts up to four digital sources — HDMI, DVI, or DisplayPort — via four HDMI inputs. A multi-function analog input on 15-pin HD connectors with balanced audio input accepts analog sources in multiple video standards. And multiple, bi-directional RS232 ports provide pass through device management from the control system.
Three HDBaseT inputs are designed for use with Atlona’s AT-UHD-EX-100CE extender and the new HDVS transmitter series with PoE. Ethernet-enabled HDBaseT signal extension also route control signals from third-party control processors via HDBaseT along with 4K/UHD audio and video through a single cable up to 328 feet. (100 meters). The web interface for the AT-UHD-CLSO-824 enables EDID management for optimizing video resolution and audio delivery and allows HDCP management for using the switcher with compliant and non-compliant devices. The switcher, while provided with a handheld IR remote control, can also be controlled via third-party control systems using IR, IP, or RS-232 formats.
In addition to providing 48V phantom power on the microphone inputs, the AT-UHD-CLSO-824 is equipped with microphone ducking, a feature which automatically lowers the audio level on the active AV input when someone speaks into the mic. The switcher is rack mountable, occupying 1U in height and full rack width, and includes a desktop power supply with detachable power cable and an IR hand held remote control.
The AT-UHD-CLSO-824 will ship in Q3 and it’s here. Leave a Comment
Share Article
Back to Top |
AMX and Microsoft Announce Partnership to Integrate Surface Hub with AMX Meeting Room Control Ecosystem
At InfoComm, Microsoft and AMX announced that they have entered into a partnership to integrate Microsoft’s Surface Hub collaboration system with AMX control.
Microsoft Surface Hub is a collaboration system that features a Windows 10-based 55″ HD or 84″ 4K display serving as a focal point for typical activities that take place during a collaboration session. Surface Hub leverages its large display to deliver applications for white boarding, content sharing and presenting, as well as running conferencing applications like Skype or Lync to easily incorporate remote participants into the meeting. Surface Hub also includes multi-touch and multi-pen capabilities that recognize up to 100 touch points with precision, allowing natural human interaction with the display for white boarding, free-flow ink drawing and execution of apps.
AMX solutions include user interfaces for managing the room technology, switching and control systems for distributing audio and video content during meetings, digital signage systems for distributing information throughout an enterprise; and software solutions that simplify the configuration, monitoring and maintenance of AV systems.
AMX is incorporating Surface Hub into its Rapid Project Maker (RPM) software. Using RPM, customers can easily set up these new rooms to be monitored and maintained in real time over the IT network with AMX’s Resource Management Suite (RMS) software.
Before people start to use the rooms for meetings, they will need a system for locating and booking available conference rooms. By integrating Surface hub with RMS, organizations can augment Surface Hub’s native calendaring and scheduling functions by placing scheduling panels directly outside the room, thereby allowing employees to instantly locate and reserve an available meeting space. RMS will also enable IT organizations to remotely monitor equipment usage, troubleshoot performance issues and remotely power down equipment in order to save energy.
More details about the partnership are here. Leave a Comment
Share Article
Back to Top |
ATOMOS Racks the 4K/UHD Shogun StudioHarnessing the latest recorder, monitor and playback technology with class leading Atomos usability and affordability, the Shogun Studio reinvents what is capable within a 3RU rack product. Designed from the ground up with the rack environment in mind, the Shogun Studio has an extensive recorder, monitor and playback deck feature set, making it perfect for the Live Event, Studio, On-set and Broadcast environment.
At its core, Shogun Studio is:
- A future proof path to 4K and 1080p60, recording to popular professional codecs like Apple ProRes, Avid DNxHR and Cinema DNG all in 10-bit 4:2:2 quality.
- Utilize the two channels for dual codec, dual resolution recording. Record simultaneously (e.g., 4K ProRes on one channel, 2K/HD DNxHD on the other) or convert or duplicate files (e.g., create a 4K ProRes version of a 4K DNxHR file).
- Powerful scheduled playback and record via Ethernet, Serial and On-screen. The combination of playlist generation and dual channel play out in 4K or down scaled HD can be used to schedule synchronized play out for video walls, signage, projection or broadcast.
- Class leading monitors and test measurement for perfect 4K viewing and set up. The 7″ 325ppi monitor offers an array of scopes, 3D LUTs, 2:1/1:1 zoom, 179 degree viewing area, safe area grid lines and can be calibrated using the optional Spyder unit.
- Powerful & intuitive AtomOS offers one touch simplicity for any operator.
- The Atomos Master Caddy for reliable, affordable open standard media — the new digital tape.
Built in continuous HDMI and SDI down conversion and down scaling from 4K to 2K/HD to any infrastructure.
- Dual redundant power supplies, for mission critical reliability.
- For ProAV integrators, the play list functionality and control via RS422, Ethernet or on screen, offers an affordable 4K and HD play out engine for video walls, signage and projection.
For Event professionals, Shogun Studio solves many of the problems faced by multi-camera events with long run times. Our Master Caddy delivers affordable and reliable media while features like time lapse, pre-roll cache and 4K/HD simultaneous recording make this the perfect choice for Event professionals.
In Mobile Production, the tight squeeze on rack space and rising recording resolutions mean that Shogun Studio will be welcomed for the ability to record, monitor, test, measure, convert and play out from a single 3RU device integrating two channels of record and playback with dual 7″ monitors.
For Security applications a wide angle lens on a 4K camera can mean a single camera replaces the equivalent of four HD cameras. The Studio Shogun, with its long record time, time lapse, record scheduling and monitor zoom capability makes it the perfect weapon for 4K security applications.
All the specs are here. Leave a Comment
Share Article
Back to Top |
Biamp Systems Expands Vocia Paging System CapabilitiesBiamp Systems today announced the release of Vocia 1.7 public address and evacuation system. With its decentralized architecture, Vocia is designed with no single point of system failure for reliable public address and paging applications in healthcare, corporate office, convention space and high-volume transportation environments.
Vocia 1.7 is equipped with new 2RU amplifiers, passive end-of-line monitoring devices (PLDs) supporting a wide range of speakers, as well as enhancements such as live inter-world paging, increased recorded message times of up to 30 minutes, and the flexibility to have multiple Life Safety Interface (LSI-16) devices per world.
The four-channel VA-4300CV and eight-channel VA-8150CV digital networked amplifiers provide power levels of 300 or 150 watts-per-channel respectively, delivering continuous audio power at the wattage needed. The 2RU amplifiers come equipped with comprehensive failover capabilities, including device-to-device and channel-to-channel failover.
Incorporating the newest Vocia Message Server (MS-1e), Vocia 1.7 also provides improved message playback, event scheduling, a VoIP paging interface, email reporting, logging capabilities and remote system access. The Text-to-Speech Servers (TTS-1e and TTS-1nce) are networked text-to-speech engines that support the creation of browser-based announcements. TTS-1 devices use Ethernet-based control protocols within a Vocia system to construct a variety of announcements using a set of user-defined templates.
Here are all the details. Leave a Comment
Share Article
Back to Top |
Crestron Adds Microsoft Surface Hub Meeting Room PackagesCrestron has extended the meeting room experience for Surface Hub users by natively integrating Microsoft’s large format collaboration device with Crestron control technology. The solution is available in two complete turnkey packages, plus optional accessories.
Built on the Crestron .AV Framework platform, these packages designed for Surface Hub deployments can be configured from Crestron’s TSW touch screen, without any programming. The integrated solution pairs an award winning, enterprise standard Crestron DigitalMedia Presentation System (DMPS), TSW touch screen, TSS scheduling touch screen and a set of USB Extenders with Surface Hub to add the flexibility of complete room control right from the conference table or Surface Hub, including the ability to:
- Display any content on the Surface Hub from any device anywhere in the room or enterprise
- Pass touch functionality from the Surface Hub to touch-compatible connected devices
- Present HD and Ultra High Definition 4K video
- Launch Windows 10 apps on the Surface Hub from the table touch screen
- Adjust room and environmental settings including shades, lights and temperature using Crestron’s app on the Surface Hub or from the Crestron TSW touch screen
- Book and schedule meetings from the Crestron TSS touch screen just outside the room
- Perform centralized enterprise room management, monitoring and control
Crestron offers a total of two base packages including options optimized for either the 55 inch Surface Hub, or the 84 inch Surface Hub which is Crestron 4K Certified, for a total of four configurations. All solutions are “Crestron Certified Designs.”
Package 1 includes a DMPS 4K presentation system, a TSW 7 inch tabletop touch screen for room control, a Crestron Connect It cable caddie for wired connectivity and simple source selection at the table, cables, and a TSS 7 inch touch screen for outside the room scheduling.
Package 2 includes everything in Package 1, and adds a Crestron AirMedia for enhanced multi-platform BYOD wireless presentation capability, and a second Crestron Connect It (TT-100) enabling increased capacity for wired connectivity.
Here are the details. Leave a Comment
Share Article
Back to Top |
Click above to learn more
|
Crestron Expands DigitalMedia With Three New 4K Presentation SwitchersCrestron is demonstrating three 4K presentation switchers that they say can be set up in just minutes without any custom programming: the HD-MD8X1-4K 4K Scaling Presentation Switcher, the DM-MD8X1-4K-C 4K Scaling Presentation Switcher with HDBaseT Output, DMPS3-4K-150-C 3-Series 4K DigitalMedia Presentation System 150.
Based on the DMP3-4K-150-C, the HD-MD8X1-4K provides up to eight inputs and has a built-in 4K scaler can convert any resolution to any other resolution, up to 4096×2160.
The 4K Scaling Presentation Switcher with HDBaseT Output (DM-MD8X1-4K-C) has the features of the HD-MD8X1-4K, plus a mic input and a DM output, so HDBaseT can be run to the room display. It’s the perfect fit for rooms larger than a huddle space.
The DMPS3-4K-150-C is designed for classrooms, small and medium conference rooms as well as and huddle spaces. It adds a 3-Series Control System and two DM inputs for a 10×1 4K switching solution, and can be used with either .AV Framework or SIMPL Windows for custom programming.
Get more details here. Leave a Comment
Share Article
Back to Top |
Hitachi Intros Four Ultra-Short-Throw LCD ProjectorsHitachi America announced the introduction of its CP-AX2505, CP-AX3505, CP-AW2505 and CP-AW3005 LCD projectors — all ultra-short-throw 3LCD designs that feature 10,000:1 contrast ratio. The CP-AX2505 and CP-AX3505 are XGA1024x768 resolution and 2,700 and 3,600 ANSI lumens, respectively, while the CP-AW2505 and CP-AW3005 are WXGA 1280×800 resolution projectors with 2,700 and 3,300 ANSI lumens brightness.
Like most projectors these days, these models can display content from either a wired or wireless connection (using an optional available wireless adapter) using a computer, USB stick or A/V source. Inputs include two HDMI inputs, VGA and, USB Type A and USB Type B ports, a composite video input and audio inputs and outputs.
All four are Ultra Short Throw projectors that feature a “Template” function that makes writing on a whiteboard easier and an optional tabletop stand allows the projectors to project images directly onto a tabletop.
Here are the detailed specs. Leave a Comment
Share Article
Back to Top |
Extron Ships Five MediaLink Plus Controllers with Ethernet Device Control and PoEExtron has shipped five new MediaLink Plus controllers including the MLC Plus 50, MLC Plus 100, and MLC Plus 200 — all three Ethernet controllers with beveled edges, rounded corners and backlit buttons. While the MLC Plus 50 features backlit Up and Down volume buttons, the MLC Plus 100 and MLC Plus 200 models feature a multi-function volume knob for smooth, precise control of select Extron amplifiers, ProDSP-equipped Extron products, and a wide range of audio devices. As part of the MediaLink Plus Series, all of these controllers are loaded with features and enhanced security, making them ideal for handling common AV functions such as display on/off, input switching, volume, and Ethernet control of AV devices. The faceplates hide the mounting screws giving the controllers a refined, uncluttered appearance. Power over Ethernet allows the controllers to receive power and communications over a single Ethernet cable. The MLC Plus 100 and MLC Plus 200 are also available in AAP versions, providing openings for up to four single-space Architectural Adapter Plates for numerous connectivity possibilities.
All of these new MediaLink Plus controllers are configured using Extron Global Configurator Plus or Global Configurator Professional software. They also integrate seamlessly with Extron’s award-winning GlobalViewer Enterprise software for complete AV resource monitoring, management, and control over a computer network. The MediaLink Plus family of controllers supports popular Web browsers and the Extron Control App.
Here are all the technical details. Leave a Comment
Share Article
Back to Top |
Panasonic Debuts 4K Projector That’s Really 5KPanasonic just introduced at InfoComm the PT-DZ21KU, the company’s first beyond 4K screen resolution projector. The PT-DZ21KU projector was shown performing image projection mapping onto a Tesla Model S (here’s the video we shot of it at InfoComm).
The PT-DZ21KU 4K+ Projector With 4K+ screen resolution (5,120×3,200) and Quad Pixel Drive technology and they say it is the most compact and lightweight 4K+ 3-chip DLP laser projector in the world. The projector is spec’d at 10,000 lumens of brightness and a contrast ratio of 20,000:1 using laser light. The projector’s pixel is shifted both horizontally and vertically at a high frame rate of 240 Hz, physically creating four different pixels from a single pixel, effectively quadrupling the pixel density of the image. To optimize for fluid, detailed, high-contrast images, the PT-DZ21KU leverages what they call a Detail Clarity Processor that analyzes pixel information. The new projector is spec’d at 20,000-hour light-source life. Providing system and installation flexibility, the Multi-Screen Support System allows screens to seamlessly join with edge blending, color matching and digital image enlarging. In addition, the PT-DZ21KU uses DIGITAL LINK — based on HDBaseT technology — that reduces cost and complexity of installation by allowing transmission of HD video, audio and control commands through a single CAT5e cable.
The PT-DZ21KU is aimed for a wide variety of applications including rental and staging, auditorium, museum, control room, and house of worship. The PT-DZ21KU will be available in the fall of 2015.
Here are all the specs. Leave a Comment
Share Article
Back to Top |
BSS Audio Introduces BLU-DAN Dante to BLU link BridgeBSS Audio has announced the introduction of its Soundweb London BLU-DAN Dante to BLU link Bridge, which allows one or more BLU link devices to be integrated with a Dante network.
The BLU-DAN connects a Dante device to one or more BLU link devices via standard Cat 5e cabling. It is capable of simultaneously transmitting and receiving up to 64 channels of Dante audio (64×64). Primary and secondary ports are provided to ensure fault tolerance and control is provided through a separate Ethernet port. The BLU-DAN’s BLU link connectivity is a low-latency, fault-tolerant digital audio bus with 256 channels.
The BLU-DAN is configurable using HARMAN’s HiQnet Audio Architect software. A wide selection of logic objects and a drag-and-drop user interface facilitate system setup. Its bi-directional locate functionality allows devices to be identified both from and within HiQnet Audio Architect.
Details are here. Leave a Comment
Share Article
Back to Top |
Kramer Announces New VIA ReleasesKramer last week launched three new VIA products: VIA PAD, an instant-present USB touch device,VIA Site Management (an IT software solution for VIA administrators) and collaboration software enhancements for VIA Collage and VIA Connect PRO.
VIA Collage is Kramer’s wireless BYOD meeting solution for any size meeting space. VIA Connect PRO offers wireless BYOD solutions for collaboration in mid-sized meeting rooms and huddle spaces.
Now, VIA Site Management (VSM) has been added to the VIA family of solutions. VIA Site Management is an IT software solution that lets administrators view and manage multiple VIA rooms within the same network. Administrators can easily and remotely monitor each device, configure and manage software updates, check each device’s status, perform resets, and more.
VIA PAD, Kramer’s new external USB touch device for Mac and PC, lets VIA Collage and VIA Connect PRO users present on the main display with a touch of a finger. Users can also present content by pressing “Step-in” inside the VIA app.
Finally, Kramer’s VIA v1.7 software update introduces 4K-UHD output for VIA Collage. VIA Collage users can present 4K-UHD content with compatible 4K-UHD displays. In addition, iOS mirroring has been added to VIA Connect PRO. VIA v1.7 includes instant file sharing with any iOS or Android device and a Do Not Disturb mode. Do Not Disturb (“DND”) mode lets someone who is presenting keep another participant from stepping in to present.
Here are the details. Leave a Comment
Share Article
Back to Top |
Extron Ships the SM 28 Fast Installing, Two-Way Surface Mount SpeakerExtron has started shipping the SM 28 SpeedMount Surface Mount Speaker, a two-way speaker with a patent pending, concealed wall mounting system. This 8 ohm speaker features an 8″ (20.3 cm) woofer with dual tuned ports and a 1.1″ (2.8 cm) tweeter. The SM 28 provides a frequency range from 59 Hz to 22 kHz, and a power rating of 90 watts continuous pink noise, 180 watts continuous program capacity.
To meet a variety of installation needs, the extremely flexible mounting system includes a 0° mounting plate and a 10° mounting adapter. The 0° mounting plate provides the electrical connections and allows the SM 28 to be oriented vertically or horizontally, flush with the wall. When the versatile 10° mounting adapter is added to the mounting plate, the SM 28 can be positioned with a 10° tilt downward, upward, left, or right.
The SM 28 saves time and installation costs for AV system contractors working with low-voltage contractors in a division-of-labor installation. During rough-in, a low-voltage contractor installs the mounting system on the wall and terminates the speaker cable to the mount’s integrated wiring contacts. Later, the AV system contractor completes the installation by sliding the SM 28 onto the mount.
The SM 28 is sold in pairs and carries a 5 year parts and labor warranty. It is available in a black or white finish and includes a 0° mounting plate and a 10° mounting adapter. Also available is an optional yoke mount kit for the SM 28. It allows for vertical or horizontal speaker mounting on a wall, or on a ceiling, and provides 180° of pivot in 10° detented steps.
Here are all the tech specs. Leave a Comment
Share Article
Back to Top |
Crestron Ships New DigitalMedia 4K Multimedia Presentation Switchers Crestron is now shipping three new 4K specified presentation switchers in the form of the HD-MD8X1-4K (an eight-input 4K Scaling Presentation Switcher via HDMI), the DM-MD8X1-4K-C (a 4K Scaling Presentation Switcher with HDBaseT output plus a mic input) and the DMPS3-4K-150-C (a 3-Series 4K Presentation System. All of them can scale any incoming resolution to 4096×2160.
Crestron says the DMPS3-4K-150-C is specifically designed for classrooms, small and medium conference rooms, and huddle spaces. It includes an integrated Crestron 3-Series Control System and two DM inputs for a 10×1 4K switching solution and can be used with either their .AV Framework or SIMPL Windows for custom programming.
Actually, all three presentation switchers are built on the new Crestron .AV Framework technology, so Crestron claims they are ready to go right out of the box. Setup can be done right from an iPad, laptop or touch screen, without custom programming. Crestron even promotes that you can walk into the room, connect your cables, specify sources and displays and the system is up and running.
Here are more tech specs:
Leave a Comment
Share Article
Back to Top |
InFocus Adds Five New Projectors Aimed at ED marketInFocus Corporation today announced its newest classroom-optimized projectors – the IN110x series. InFocus designed the five new projectors, which each feature 3200-lumen brightness and 15,000:1 contrast ratio, to fit school budgets and the ambient-light levels of most classrooms. Each model has a majority of the same connectivity options, but differ in native resolution, aspect ratio, throw ratio and zoom ratio in order to fit classrooms’ differing screen shapes and throw distances.
The new IN110x-series projector line includes the IN112x, IN114x, IN116x, IN118HDxc and the IN119HDx, each with a list price of less than $550.
The IN119HDx and IN118HDxc offer full native 1080p high-definition resolution, the IN116x offers widescreen WXGA, the IN114x offers standard XGA, and the IN112x offers SVGA resolution. Each projector produces an image up to 299 inches (nearly 25-feet diagonal), is 3D ready and offers VGA and HDMI inputs.
Here are all the technical specs on each one. Leave a Comment
Share Article
Back to Top |
Da-Lite Unveils New Product for Large Venue InstallsWhen designing large venues, ballrooms or architecturally appealing rooms, a consultant, integrator or architect may feel conflicted when installing a traditional screen in a room with high ceilings that will require a lot of black drop to accommodate the AV needs and an appropriate screen viewing height. The Wireline Advantage from Da-Lite is the aesthetic solution to this design challenge.
The Wireline Advantage is a projection screen for large venues that uses thin steel cables instead of black drop to lower the viewing area to an appropriate height for the audience. The result is stunning with a large screen that is almost invisibly suspended at the right viewing height, leaving the architecture of the room exposed.
The Wireline Advantage housing can be ceiling recessed and features the easy installation brackets and self-trimming edge that is inherent to the Advantage line. The Wireline Advantage will feature cable lengths up to 29 feet, and will be available to order in November 2015.
Here are the details from a video we shot at InfoComm. Leave a Comment
Share Article
Back to Top |
|
For all you REGULAR readers of rAVe ED [Education] out there, hopefully you enjoyed another opinion-packed issue!
For those of you NEW to rAVe, you just read how we are — we are 100 percent opinionated. We not only report the news and new product stories of the ProAV industry, but we stuff the articles full of our opinions. That may include (but is not limited to) whether or not the product is even worth looking at, challenging the manufacturers on their specifications, calling a marketing-spec bluff and suggesting ways integrators market their products better. But, one thing is for sure, we are NOT a trade publication that gets paid for running editorial or product stories. Traditional trade publications get paid to run product stories — that’s why you see what you see in most of the pubs out there. We are different: We run what we want to run and NO ONE is going to pay us to write anything good (or bad).
Don’t like us? Then go away — unsubscribe! Just use the link below.
To send us feedback, don’t reply to this newsletter. Instead, write directly to founder Gary at gary@ravepubs.com or Editor-in-Chief Sara Abrons at sara@ravepubs.com
Everything we publish is opt-in — we spam NO ONE! rAVe ProAV Edition is our flagship publication with what we believe is a reach of virtually everyone in the ProAV market. rAVe HomeAV Edition is co-published with CEDIA, covering the HomeAV market. We added rAVe Rental [and Staging] in November 2007, rAVe ED [Education] in May 2008 and then rAVe DS [Digital Signage] in January 2009. We added rAVe GHGav [Green, Healthcare & Government AV] in August 2010 and rAVe HOW [House of Worship] in July 2012. You can subscribe to any of those publication or see ALL our archives by going to: https://www.ravepubs.com
To read more about rAVe’s team and what we do, go to https://www.ravepubs.com Back to Top |
Copyright 2015 – rAVe [Publications] – All rights reserved. For reprint policies, contact rAVe [Publications], 210 Old Barn Ln. – Chapel Hill, NC 27517 – (919) 969-7501. Email: Sara@rAVePubs.com
rAVe contains the opinions of the author only and does not necessarily reflect the opinions of other persons or companies or its sponsors. |
|
|
|
