New Premium Analog Audio Breakout Cables for BrightEye Converters from Laird

analog-cable-0915Laird Digital Cinema just debuted a new line of analog audio I/O breakout cables for use with Ensemble Designs’ BrightEye converters. Laird multi-pin HD15 breakouts are designed for connectivity using a four-channel audio cable. The 12-inch “fan-out style cable” includes Neutrik 3-Pin XLR connectors which feature a durable zinc die cast shell and chuck type strain relief for secure clamping. Cables are available for specific Bright Eye models and are manufactured in the U.S. The Laird ED-BE-2XMF-003 HD15 to XLR Male & Female Analog Audio I/O Breakout Cable for Ensemble Designs BrightEye 30/30D is designed for superior connectivity with high quality, four-channel audio cable and XLR connectors. Cables are built with 24AWG stranded bare copper and are polypropylene insulated, individually shielded and jacketed with an overall heavy duty CL2 PVC jacket.

Features include:
  • Two Neutrik NC3FX Female 3-Pin XLR Connector
  • Two Neutrik NC3MX Male 3-Pin XLR Connector
  • 15 Pin HD
  • Industry standard AMP DSub cable hood
  • 3-foot audio cable with12-inch fan out
  • High quality 24AWG audio cable
Other specifications include:
  • Capacitance: 25 pF/ft. @ 1 kHz
  • Cond.-Shield Capacitance: 45 pF/ft. @ 1 kHz
  • Characteristic Impedance: 60ohms NOMINAL
  • D.C. Resistance @ 20°C: 24.5ohms/1000′
